Features & benefits
.png)
Category
Projection / Focus Light
Light Source
High Efficiency LED
Housing
Die-Cast Aluminium
Diffuser
Clear Toughened Glass
Control
ON / OFF (DMX Optional for RGB / RGBW / RGBWW)
Ingress Protection
IP65
Mounting
Adjustable Bracket
Application
Column Highlighting / Feature Lighting / Architectural Accent
Performance overview
| Power range | Beam angle (°) | Effective throw |
|---|---|---|
| 10-15W | 15°-25° | 15-30 ft |
| 20W | 10°-15° | 25-45 ft |
| 30W | 10° | 40-70 ft |
| 40-50W | 5°-10° | 70-120 ft |
Technical data
| Model | Power | Length | Voltage | CCT / colour | IP | Mounting |
|---|---|---|---|---|---|---|
| RIL-204-10-15 | 10-15 W | WW / RGB / RGBW / RGBWW | IP65 | Adjustable Bracket | ||
| RIL-204-20 | 20 W | WW / RGB / RGBW / RGBWW | IP65 | Adjustable Bracket | ||
| RIL-204-30 | 30 W | WW / RGB / RGBW / RGBWW | IP65 | Adjustable Bracket | ||
| RIL-204-40-50 | 40-50 W | WW / RGB / RGBW / RGBWW | IP65 | Adjustable Bracket |
